Updated: 6.2.04

This image of M3 was taken mainly to test out a replacement minus violet filter for the Optec 0.5x focal reducer. The first filter caused significant image degradation (distorted star shapes), but this filter does a nice job. There is some astigmatism present, which needs to be resolved. This shows up in an one-shot image as elongations in the red and blue frames, but 90 deg to each other. Further tests will be done to isolate scope from focal reducer.

Return to new images


Image info:

12"LX200 on a Losmandy Titan Mount

Starlight Express

25x2 mins

f/5.3 (Optec FR)

Acquired and processed in Maxim (no darks and no flats)

guided with an STV on a piggybacked Sky90 refractor


Home driveway
